[ollydbg-binary-execution-visualizer] New Tool for Visualizing Binaries With Ollydbg and Graphvis

Sometimes crackme’s or something you might be reversing will constantly bug you due to the excessive usage of f7 & f8. It will be quiet neat if you can see how the application is executing visually and set your break points accordingly.

Requirements:

o Ollyscript plugin

o Bunch of your favorite anti-­‐debug plugins (phantom , ollyadvanced, …etc) o Pygraphviz

o Graphviz

o Python 2.7

Approach:

• Create an ollyscript that will do the following


  o Log all EIP for main application
  o Disregard to log calls to kernel32 , ntdll & addresses which are above


  7C000000 using step over not step into include more addresses to
  exclude if needed later for other system dll’s 77000000 … etc. o Save EIP Logs to file
• Parse the log file
• Feed it into pygraphviz
• Export to png
• Visualize & note needed breakpoints.
• Re-­‐run the app setting above breakpoints.

Full documentation here

Download ollydbg-binary-execution-visualizer
